LT-101-USB

Concurrently captures 2 inputs of any of the following standards:

1920 x 1080, Progressive
p60/59.94/50/30/29.97/25/24/23.98 via 3G-SDI or HD-SDI​

1920 x 1080, Interlaced
i60/59.94/50 via 3G-SDI or HD-SDI-​

1280 x 720, Progressive
p60/59.94/50 via HD-SDI​

720 x 576, Progressive
p25 via SD-SDI (PAL)​

720 x 576, Interlaced
i50 via SD-SDI (PAL)​

720 x 480, Progressive
p30/29.97 via SD-SDI (NTSC)​

720 x 480, Interlaced
i59.94 via SD-SDI (NTSC)

Specifications and Features

Interface

Inputs:

  • DVI-I (supports both digital DVI-D and analog VGA/RGB)​

  • VGA​

  • RGB component​

  • S-video​

  • Composite video​

Outputs:

  • USB 2.0 or USB 3.0 interface​

  • Bus-powered via USB connection​

  • Compact external form factor

Video Engine

  • Hardware-based compression engine for minimal host CPU load​
  • Full frame rate HD frame grabber for simultaneous uncompressed video capture​
  • Advanced hardware deinterlacing​
  • Video downscaling prior to compression​
  • Denoise filter prior to compression​
  • Text overlay prior to compression​
  • HD compression coprocessor functionality​

Signals

1920 x 1080, Progressive
p30/29.97/25/24/23.98 via DVI-I or VGA​

1920 x 1080, Interlaced
i60/59.94/50 via DVI-I

1280 x 720, Progressive
p60/59.94/50 via DVI-I or VGA

720 x 576, Progressive
p25 via composite/S-video (PAL)​

720 x 576, Interlaced
i50 via composite/S-video (PAL)​

720 x 480, Progressive
p30/29.97 via composite/S-video (NTSC)​

720 x 480, Interlaced
i59.94 via composite/S-video (NTSC)

Software

OS:

  • Windows: XP, Vista, 7, 8, 10, 11 with DirectShow support​

  • Linux support​

  • No driver installation required (UVC compliant)​

Video Compression:

  • H.264 video codec​

  • VC-1/WMV-HD video codec​

  • Windows Media compression​

Audio:

  • Synchronized stereo audio capture​

  • WMA audio codec​

Software Support:

  • DirectShow compatibility​

  • Windows Media Services support​

  • Silverlight support​

  • Simple SDK for easy integration​

  • Can compress video from host via USB (coprocessor mode)

Others

bla
bla

Bla
Bla

Full specifications and Features

Driver

ProductBrief

SDK

v1.4.0

1.89 MB | 12/28/2025

Changelog:

  • Superior Video & Audio

    • Enhanced playback with advanced deinterlacing and interlaced video support for smoother visuals.

    • MP3 and AAC audio encoding enabled for expanded compatibility and higher-quality recordings.

  • Smarter File Management

    • New auto-increment file naming and safer split recording to prevent overwriting and make file management seamless.

    • Expanded support for flexible recording sizes and new audio formats.

  • Firmware & Compatibility

    • Robust updates and optimizations for LT311 players and DDR memory, allowing more reliable multi-stream HD operation.

    • Latest Windows and Ubuntu 24.04 driver/support for optimal integration with modern systems.

  • Developer Experience

    • Refined Python and C++ SDKs with improved documentation, updated code examples, and API standardization.

    • Easier device programming through new JTAG & UART integration.

  • Performance & Stability

    • Faster, more accurate audio pipelines, increased system stability, and bug fixes to core services.

    • FFmpeg integration expanded for smoother encoding and muxing workflows.
